Planet-friendly. Picture perfect.
The VG2236wm-LED is one of two new members of ViewSonic’s new VG36-LED family. Its 22" (21.5" viewable) display with a native 1920x1080 resolution is big enough to replace dual-monitor setups. What makes it even more appealing is the LED backlight for up to 50% energy savings. Monitor is also fully ergonomic with 90º pivot, height adjust, swivel and tilt. The slim bezel design coupled with hidden stereo speakers make VG2236wm-LED a space saver. You can put it on your desk or mount on your wall or on any VESA compliant monitor stand. With Viewsonic’s strongest pixel performance guarantee and 3-year limited warranty, you will have peace of mind in your investment.SPECIFICATIONS
- LCDContrast Ratio: 1000:1 (typical)
Viewing Angles: 170° (H), 160° (V)
Brightness: 250cd/m² (typical)
Optimum Resolution: 1920×1080
Response Time: 5ms (typical)
Light Source: 25,000 Hours (min.)
Panel Surface: Anti-Glare, Hard coating (3H)
Pixel Pitch: 0.24825 mm x 0.24825 mm (H×V)
Size: 55cm/21.5”wide Colour TFT Active Matrix LCD aspect ratio
Dynamic Contrast Ratio: 20,000,000:1 - COMPATIBILITYPC: VGA up to 1920x1080 Non Interlaced
Mac®: 1920x1080 Non Interlaced - DIMENSIONSPhysical (WxHxD): 521.21mm (W) x 427.41 mm (H) x 239.2mm (D)
- REGULATIONSUL, CUL, FCC-B (ICES), CB, CE, CES-003B, ISO13406-2, TUV/GS,ERGO, TUV-S, NOM, GOST-R,
HYGIENIC (20 copies), CCC, BSMI, PSB, C-TICK, MIC(KCC), SASO, WEEE, RoHS, SASO, Ukraine, TCO 5.0 - INPUTSync: H/V separated (TTL), composite sync-on-green
Analogue: RGB Analogue (75 ohms, 0.7 / 1.0 Vp-p)
Frequency: 24–83kHz / 50–75Hz - CONNECTORAnalogue: 1×15 pin mini D-sub
Digital: DVI
Audio: 1 x 3.5 mm
Power: 3-pin plug (CEE22) - POWERVoltage: AC 100-240V (Universal); 50/60Hz
Consumption: 22 W (typical)
Save Mode (W): <= 0.1W - CONTROLSBasic: [1], [2], power button, Down[▼], Up[▲]
OSD: Auto Image Adjust, Contrast/Brightness, Input Select, D-SUB, DVI, Colour Adjust, sRGB,
9300K, 7500K, 6500K, 5000K, User Colour [R, G, B],
Information Manual Image Adjust, H/V Position, Horizontal Size, Fine Tune, Sharpness,
Dynamic Contrast, Aspect ratio, Setup Menu, Language, Resolution Notice,
OSD Position, OSD Timeout, OSD Background, OSD Pivot, Auto power off, Memory
Recall - VESA MOUNT COMPLIANT100mm× 100mm
- ERGONOMICSTilt: 20˚~-5˚
Swivel: 360˚
Height Adjustment: 0~135mm
Pivot: 90˚ - AUDIOSpeakers: 2x2W
- WEIGHTNet: 4.4 Kg (9.7lbs
- OPERATING CONDITIONSHumidity: 20 - 90 (%)
Temperature: 0 - 40 (°C) / 32 - 104 (°F)
