Affordability without compromise
ViewSonic's RELIABLE PERFORMER DELIVERS ON A PROMISE OF QUALITY STANDARDS like 250cd/m2 of brightness and 1000:1 contrast ratio or stunning, bright images. The VA705b features a 5ms video response time that produces crystal-clear graphics and HD quality video for full brilliant, detailed color. SIMPLICITY IS EXECUTED THROUGH ITS CLEAN LINES, SLIM BEZEL. The VESA® wall mount makes the VA705b an unobtrusive integration to any decor. Packed with a powerful OnView® control interface, precise performance is always a priority in this extremely affordable package. The stylish VA705 LCD display is an ideal choice for SOHO, education and government users.
SPECIFICATIONS
- COLORSBlack
- LCDContrast Ratio: 1000:1 (typical)
Viewing Angles: 160° (H), 160° (V)
Optimum Resolution: 1280×1024
Response Time: 5 (typical)
Light Source: 50,000 Hours (minium)
Panel Surface: Anti-Glare, Hard coating (3H)
Pixel Pitch: 0.264 x 0.264 (mm)
Colour Support: 16.7 Millions (Millions of colours)
Size: 43cm / 17" Color TFT Active Matrix LCD
Brightness: 250 (typical)
Dynamic Contrast Ratio: 6000:1 (typical)) - COMPATIBILITYPC: VGA up to 1280×1024 Non Interlaced
Mac®: 1280×1024 Non Interlaced
- DIMENSIONSPhysical With Stand: 379 × 400 × 210 (mm) / 14.92 × 15.75 × 8.27 (inch)
- REGULATIONSUL, CUL, FCC-B (ICES), CB, CE, TCO'5.0, ICES-003B, ISO13406-2, TUV/GS, TUV
ERGO(covers ISO13406-2 & MPRII), TUV-S, NOM, GOST-R, HYGIENIC (20 copies), Energy
Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS, TCO 5.0 - INPUTSync: Separate Sync
Analogue: RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Frequency: 24–82kHz / 50–75Hz - CONNECTORAnalogue: 1×15 pin mini D-sub
Power: Built-in power Adapter, 3-Pin plug - POWERVoltage: AC 100-240V (Universal); 50/60Hz(Switch)
Consumption: 19W (typical) / 20.5W (maximum)
Save Mode (W): <= 1W - CONTROLSBasic: [1], [2], Power, Down[▼], Up[▲]
OSD: Auto Image Adjust, Contrast/Brightness, Color Adjust, sRGB, 9300K, 6500K, 5400K, User
Color [R, G, B], Information, Manual Image Adjust H/V Position, Horizontal Size, Fine
Tune, Sharpness, Setup Menu Language, Resolution Notice, OSD Position, OSD
Timeout, OSD Background, OSD Pivot, Memory Recall - VESA MOUNT COMPLIANT100 × 100
- WEIGHTNet: 4.03 kg / 8.88 lb
- OPERATING CONDITIONSHumidity: 10 - 90 (%)(non-condensing)
Temperature: 0 - 40 (°C) / 32 - 104 (°F)
