Professional Viewing Quality for Business Users
Experience a lifelike viewing experience with one of ViewSonic’s 22” Full HD 1080p LED displays –the VA2212a-LED. Incorporating an ergonomically accommodating 16:9 widescreen ratio supported by a LED backlit panel, the VA2212a-LED provides professional viewing quality for both business users and home entertainment.ViewSonic also participates in the energy-saving revolution with its new-generation LED backlighting. Exclusive ECO Mode reduces cost and maintenance efforts for corporate users while constructing vivid images with sophisticated details and high colour saturation. Along with a 10,000,000:1 high dynamic contrast ratio, the VA2212a-LED automatically detects the brightness and darkness of input signals to adjust LED backlighting appropriately. The VA2212a-LED also has embedded sRGB colour correction technology whichdisplays an impressive landscape to enhance the viewing experience. This stylish monitor is ideal for any office or corporate environment.
SPECIFICATIONS
- LCDContrast Ratio: 1,000:1 (typ.)
Viewing Angles: 170° / 160° (typ.)
Brightness: 250 cd / m²
Display Area: 54.6cm (21.5”) wide
Optimum Resolution: 1920 x 1080
Response Time: Typ. 5 ms
Panel Surface: Anti-glare type, 3H hardness
Pixel Pitch: 0.24 mm x 0.24 mm
Dynamic Contrast Ratio: 10,000,000:1
Backlight: White-light LED
Backlight Life: 30,000 hours (min.) - COMPATIBILITYPC: VGA up to 1920 x 1080
Mac®: MAC up to 1920 x 1080 - DIMENSIONSPhysical With Stand: 511.1 x 391.8 x 189.9mm(W x H x D) (20.1” x 15.4” x 7.4”)
Physical Without Stand: 511.1 x 309.4 x 52.7mm(W x H x D) (20.1” x 12.2” x 2.1”)
- REGULATIONSCE, CB, WEEE, RoHS, REACH SVHC List,
TCO, Energy Star®, Vista Basic, Windows 7,
UL, cUL, FCC-B / ICES-003B, Nemko ERGO,
GOSTR+, Hygienic, UkrSEPRO, ErP, CCC,
CEL Level 1, BSMI, PSB, C-TICK - INPUTSync: Separate Sync
Analogue: RGB analog (75 Ω, 0.7 / 1.0 Vp-p)
Frequency: Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz - CONNECTORAnalogue: D-sub x 1
Power: Internal Power Board , 3-pin Plug (CEE22) x 1 - POWERVoltage: AC 100 - 240V (universal); 50 / 60 Hz
Consumption: 20W - VESA® MOUNT100mm x 100mm
- ERGONOMICSTilt: 22° ~ -5°
- WEIGHTNet With Stand: 2.91 Kg (6.42 lbs)
Net Without Stand: 2.6 Kg (5.72 lbs) - OPERATING CONDITIONSHumidity: 10% to 90% (no condensation)
Temperature: 32° F to 104° F (0° C to 40° C)
