OVERVIEW
ViewSonic’s 32" CD3225 Commercial Display is designed for use in educational, retail, public and commercial signage applications. Full 1080p resolution and nearly 178º horizontal and vertical viewing angles provide a clear view in any installation. Multiple connectivity and resolutions provide many options for showing a diverse set of digital signage content; from movies, to internet pages, PowerPoint, Flash, and much more with ultimate HD clarity. Display your vivid graphics and stunning video beautifully with this bright and high contrast commercial display.SPECIFICATIONS
- COLORSBlack
- LCDType: 32" color TFT active matrix, wide LCD
Contrast Ratio: 5000:1 (typ)
Viewing Angles: 178º horizontal, 178º vertical
Brightness: 450 cd/m2 (typ)
Display Area: 27.48" horizontal x 15.47" vertical; 31.5" diagonal
Optimum Resolution: 1920x1080, 0.36375mm dot pitch
Response Time: 8ms
Light Source: Long life, 50,000 hrs. (typ)
Aspect Ratio: 16:9
Panel Surface: Anti-glare - DIMENSIONSPhysical (WxHxD): 29.2" x 18.6" x 5.1" (775.6mm x 472.6mm x 128mm)
Packaging: 33.6" x 26.5" x 13.9" (855mm x 675mm x 355mm)
- AUDIOSpeaker: 6Wx2
- INPUTAudio: 3.5mm jack
Video Input: HDMI, DVI, VGA, S-Video, CVBS
Control Input/Output: RS-232/RS-232 - CONNECTORDigital: HDMI, DVI
Power: 3-pin plug
Analog: 15-pin mini D-sub (VGA) - POWERVoltage: AC 100–240V (universal), 50–60Hz / DC 24V, 4.1A
Consumption: 100W (typ) - CONTROLSPicture: Pictue Mode, Contrast, Brightness, Color, Tint, Sharpness,
Backlight, DCR, Color Temperature
Audio: Volume, Mute
Front Panel: Input, Menu, Up, Down, Left, Right, Power
OSD: Aspect Ratio, PIP, Video Source, Auto Adjustment, Clock,
Frequency, Phase, H. Possition, V. Position, 3D Comb, Blue Screen
Special: Language, Overscan, Power Save, Set Monitor ID, Image
Rentaton, Auto Adjsutment, Reset All Setting, Diagnostic - VIDEO SIGNALVideo: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
- WEIGHTNet: 35.3 lb. (16 kg)
- OPERATING CONDITIONSHumidity: 20–80% (non-condensing)
Temperature (landscape): 32–104ºF (0–40ºC)
Temperature (portrait): 41–95ºF (5–35ºC)
