VPC12-WPO-7

PC OPS con Windows para pantallas interactivas ViewBoard®

Intel Core i5-7200U con vPro y función TPM
Intel HD graphic 620
Memoria gráfica total disponible: 64 GB
Resolución máxima hasta 4096x2304@60Hz

Sales Enquiry

GALLERY

OVERVIEW

El ViewSonic® VPC12-WPO-7 PC OPS es la solución integrada ideal para las pantallas interactivas ViewBoard®. Con conectividad por cable, Wi-Fi de doble banda y Bluetooth, un potente procesador Intel® Core™ i5-7200U, 8GB (ampliable hasta 16GB) de memoria DDR4 SO-DIMM, y (ampliable hasta 512GB) de almacenamiento SSD, el VPC12-WPO-7 contiene la potencia de computación necesaria para el funcionamiento con aplicaciones de uso intensivo de la CPU.

SPECIFICATIONS

Core
CPU: Intel® Core™ i5-7200U with vPro and TPM function
Graphics: Intel® HD Graphics 620, Total Available Graphics Memory: 64GB, Max Resolution up to 4096x2304@60Hz
Memory
Type: DDR4 SO-DIMM
Capacity: 8GB (up to 16GB)
Software
Operating System: Free Dos

Storage
Dimension: 2.5"
Capacity: 128GB SSD (up to 512GB)
Interface: SATA3 6GB/sec
INPUT
MIC(Microphone): x1
OPS: Yes
OUTPUT
HDMI: x1 (max. resolution 4096x2160@24Hz)
Audio: x1 (Line Out)
LAN
RJ45: x1 (Integrated 10/100/1000M Adaption)
Wireless / Bluetooth
Wireless / Bluetooth: Intel® Dual Band Wireless-AC 8260, 802.11 a/b/g/n/ac (2.4GHz/5GHz) / BT4.2 ; BLE
USB
Type A: USB3.0x2, USB2.0x2
Support Media Format
Video format: Container: ASF, WMA, WMV, WM, ASX, WAX, WVX , WMX, WPL, WMD, AVI, MPG, MPEG, M1V, MP2, MP3, MPA, MPE, M3U
Image format: Container: JPG, JPEG, JPE, JFIF, BMP, , DIB, PNG, GIF, TIF, TIFF
Audio codec: Container: MID, MIDI, RMI, AIF, AIFC, AIFF, WAV, CDA
Power
Voltage: DC 12/19V
Consumption: 60W
OPERATING CONDITIONS
Temperature (º C): -5°C to 45°C
Humidity: 10% ~ 90% non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 7.1 x 4.7x 1.2 in/180 x 119 x 30mm
Packaging (inch / mm): 10.0 x 7.7 x3.1 in/254 x 196 x 77 mm
WEIGHT
Net (lb / kg): 1.85lb/0.84kg
Gross (lb / kg): 2.31lb/1.05kg
REGULATIONS
REGULATIONS: FCC, cTUVus
PACKAGE CONTENTS
PACKAGE CONTENTS: 1. VPC12-WPO , 2. QSG
