OVERVIEW
ViewSonic’s 22-inch VA2232w-LED display is a new memberof the VA series; with a native 1680 x 1050 resolution andsRGB colour calibration function, this model presentsexquisite picture quality and an immersive viewing experience.Along with an impressive 10,000,000:1 dynamic contrast ratio,the VA2232w-LED automatically detects and adjusts dark andbright levels to greatly enhance greyscale and colour contrastperformance. Save energy and money with ViewSonic’sECO Mode solution which reduces power consumption andextends backlight life. The VA2232w-LED provides great valueconcerning viewing performance and is an excellent solutionfor home and business.SPECIFICATIONS
- COLORSBlack
- LCDRatio de contraste: 1000:1 (typ.)
Ángulos de visión: 170° / 160° (typ.)
Área de visualización: 22" wide
Resolución óptima: 1680 x 1050
Tiempo de respuesta: 5 ms
Superficie del panel: Anti-glare type, 3H hardness
Brillo : 250 cd/m²
Relación de contraste dinámico: 10,000,000:1
Retroiluminación: LED
Vida útil de retroiluminación: 40,000 hours (min.) - COMPATIBILIDADPC: VGA up to 1680 x 1050 (non-interlaced)
Mac®: Power MAC (up to 1680 x 1050)
- DimensionesFísicas con la base: 510.7 x 416.2 x 195.4 mm (20.1” x 16.4” x 7.7”)
Físicas sin la base: 510.7 x 352.4 x 61.2 mm (20.1” x 13.9” x 2.41”) - NormativasCE, CB, WEEE, RoHS, REACH SVHC List,
Windows XP / Vista premium, Window 7,
UL, cUL, FCC-B / ICES-003B, UL-AR / TUV-S,
NOM, Nemko ERGO, GS, GOST-R+Hygienic,
UkrSEPRO, ErP, CCC, CEL level 1
BSMI, PSB, C-tick, SASO, TCO - EntradaSyncronización: Separate sync
Analógico: RGB analog (75 Ω, 0.7 / 1.0 Vp-p)
Frecuencia: Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz
Digital: DVI (TMDS, 100 ohms) - ConectividadDigital: DVI- D x 1
Analógico: 15-pin mini D-sub x 1 - AlimentaciónVoltaje: AC 100 - 240V (universal); 50 / 60 Hz
- VESA® MONTAJE100mm x 100mm
- ERGONOMÍAInclinación: 20° ~ -5°
- PesoNeto con base: 3.91 Kg
Neto sin base: 3.54 Kg - CONDICIONES DE FUNCIONAMIENTOHumedad: 10% to 90% (no condensation)
Temperatura: 32° F to 104° F (0° C to 40° C) - CONNECTORSPower: Internal power board, 3-pin plug (CEE22) x 1
