- Dimensiones
Físicas con la base: 472 x 408 x 225
Físicas sin la base: 472 x 327 x 65
Embalaje (LxAxP): 526 x 448 x 127
- Normativas
TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R, Hygienic (20 copies), UL, cUL, FCC-B (ICES), ICES-003B, NOM, SASO, ENERGY, ENERGY STAR, C-Tick, KTL/MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark CCC, VCCI, WEEE, RoHS
- CONTENIDO DE LA CAJA
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- AUDIO
Altavoces: 2x2.5-watts
- Conectividad
Analógico: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable) (HDCP enabled)
Alimentación: 3-pin AC plug (CEE22)
- Alimentación
Voltaje: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumo: 38 watt (typ.), <1 watt in power save mode
- CONTROLES
Básico: Power, menu [1], up, down, select [2]
Menú en pantalla: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall
- CONDICIONES DE FUNCIONAMIENTO
Temperatura: 0°C–40°C
Humedad: 20%–90% (non-condensation)
- Peso
Neto con la base: 4.9kg
Bruto: 6.4kg
- Entrada de vídeo
Frecuencia: Fh: 24–82kHz, Fv: 50–75 Hz
Syncronización: H/V separate (TTL), composite, sync on green
Analógico: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Digital: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
- GESTIÓN DE ENERGÍA
TCO’03 and ENERGY STAR standards
- SEGURIDAD
Kensington security port
- MONTAJE EN LA PARED
VESA FDMI 100mm x 100mm
- ERGONOMÍA
Inclinación: -5°/+20°
