“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
High Impact 1080p Digital Signage
ViewSonic’s 46” CD4620 Commercial Display delivers STUNNING FULL HIGH DEFINITION CONTENT TO YOUR AUDIENCE FOR THEIR VIEWING PLEASURE. This 1080p LCD panel displays stunning images at almost print-quality resolution in your Digital Signage applications. VGA input and output plus RS-232 input allows you to DAISY CHAIN MULTIPLE DISPLAYS into the signage network and still be able to control each display individually. Other inputs include HDMI, S-VIDEO, COMPONENT, COMPOSITE and PC-VGA. Wide viewing angles, high brightness and contrast and 1920 x 1080 native resolution ensure crystal clear images in virtually any room or lighting conditions. A fast 6ms response time delivers crisp scrolling text or videos. The CD4620 sets a new standard for large format, high impact Digital Signage solutions.
REVIEWS
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
SPECIFICATIONS
- COLORSBlack
- LCDTipo: 117 cm / 46" wide colour TFT active matrix, 1920 x 1080
Ratio de contraste: 1500:1 (typ.)
Ángulos de visión: 176° horizontal, 176° vertical (at 10:1)
Brillo : 450cd/m² (typ.)
Superficie de cristal: Anti-glare, hard coating (2H)
Área de visualización: 101.8 cm horizontal x 57.3cm vertical, 116.8cm diagonal
Tiempo de respuesta: 6ms (grey-to-grey)
Relación de aspecto: 16:9
Resolución nativa: 1920 x 1080
Gama de colores: 16.7M colours supported (8-bit) - DimensionesFísicas (AnxAlxP): 1122 x 663 x 138 mm (without stand)
- NormativasCE, CB, GOST, UL/cUL, FCC, NOM, WEEE, RoHS
- CONTENIDO DE LA CAJALCD display, 1.8m power cables (Europe [Schuko]/UK), remote control, batteries, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- AUDIOSeñal: 2 x 10 watt with SRS TruSurround¹
- SEÑAL DE ENTRADATV/Vídeo comp.: 480i, 480p, 720p, 1080i, 1080p
Frecuencia: Fh: 31-91kHz,
Fv: 50-75Hz
Digital: HDMI (HDCP enabled; TMDS, 100 ohm)
Syncronización: H/V separate (TTL) - ConectividadSalida de audio : 1 x RCA (left/right)
2 x speaker connectors (for optional speakers)
Entrada de vídeo compuesto: 1 x RCA (CVBS)
Entrada S-Video: 1 x 4-pin mini DIN jack (Y/C)
Entrada de vídeo por componentes: 1 x RCA set (YPbPr/YCbCr)
Entrada de audio: 1 x 3.5mm mini stereo
2 x RCA (left/right)
Entrada analógica: 1 x 15-pin mini D-Sub (detachable cable)
Salida analógica: 1 x 15-pin mini D-Sub (detachable cable)
Salida de vídeo compuesto: 1 x RCA (CVBS)
1 x BNC
Alimentación: 3-pin plug
Control/salida de red: 1 x D-sub RS-232
Control/entrada de red: 1 x D-sub RS-232 - AlimentaciónVoltaje: AC 100–240V (universal), 50/60Hz
Consumo: 285 watt (max.), <5 watt in power save mode - CONTROLESBásico: Power, menu, exit, source, channel +/-, volume +/-, main power switch
Menú en pantalla: Picture Menu (brightness, contrast, sharpness, black level, NR, tint, colour, colour temperature [10500K, 9300K, 7500K, 6500K, User-RGB], picture reset), Screen Menu (H/V position, H size, fine tune, zoom [H&V zoom, H zoom, V zoom, H/V zoom position], screen reset), Audio Menu (balance, treble, bass), PIP Menu (PIP size, PIP audio source, PIP reset), Configuration Menu (auto setup, auto adjust, power save, language [English, French, German, Russian, Simplified Chinese, Spanish], screen saver, colour TV system, OSD turn off, information OSD, off timer, OSD H/V position, display information, config. reset), Advanced Menu (input resolution, black level expansion, Gamma, scan mode, scan conversion, film mode, remote control, display ID, tiling [H/V monitors, position, frame compensation, enable], date/time, auto on/off scheduler [day, hour, minute, input], DDC/CI, advanced reset) - CONDICIONES DE FUNCIONAMIENTOTemperatura: 0°C–40°C
Humedad: 10–85% (non-condensing) - PesoNeto: 34.6kg (with optinal stand), 29.3kg (without stand)
Bruto: 35.9kg - Entrada de vídeoAnalógico/Digital: HDMI (x2), S-video, component, composite, RCA (x2)
- MONTAJE EN LA PAREDVESA FDMI 400mm x 200mm, M6 screws
