Key Features
  • Impressively large, bezel-free visual experiences
  • All-in-One design without complicated setup
  • Real-to-life colors and high brightness
  • Immersive audio from built-in Harman Kardon speakers
  • Adaptable and flexible to suit any display scenario
  • Effortless full-front maintenance

LDP216-251
Product Description
Erleben Sie verblüffend naturgetreue Bilder auf dem minimalistischen ViewSonic® LDP216-251 All-in-One Direct View LED-Display der zweiten Generation. Das modulare All-in-One-Design bietet einen mühelosen Installations- und Wartungsprozess. Dieses Display der nächsten Generation ist mit fortschrittlichen Funktionen ausgestattet, um ein spektakuläres audiovisuelles Erlebnis und ein benutzerfreundliches Design zu bieten. Mit einer 120%igen Rec. 709-Farbskala, einer blitzschnellen Bildwiederholfrequenz von bis zu 4.440 Hz und einer Spitzenhelligkeit von 600 nits wird jedes Video, jede Präsentation oder jeder Vortrag zu einem Erlebnis mit lebensechten Farben und ußergewöhnlichen Details. Das Display ist außerdem mit Harman Kardon-Lautsprechern, 4K/HDR/HLG-Unterstützung und Frame Interpolation-Technologie für eine optimale, authentische Darstellung von Inhalten ausgestattet. Mit einer Dicke von 25 mm und einer rahmenlosen Kante von 5 mm strahlt das schlanke Display Raffinesse und Eleganz in jeder modernen Umgebung aus. Es bietet Flexibilität und Anpassungsfähigkeit im Design - mit Installationen im Hoch- und Querformat, um jeden Raum und jedes Szenario zu ergänzen. Die Bildschirme können problemlos zu einer ultrabreiten 32:9-Videowand zusammengefügt werden, um ein nahtloses visuelles Erlebnis in epischen Proportionen zu bieten. Die Systemsteuerungsbox lässt sich leicht abnehmen, um sich in jedes Design einzufügen.
  1. Power Switch
  2. Harman Kardon Speakers
  3. HDMI Out
  4. Audio Out
  5. S/PDIF Out
  6. IR In
  7. USB 2.0 (5V/1.5A) x 2
  8. LAN & Control
  9. HDMI 2.0 x 2
  10. HDMI 1.4 x 2
  11. HDMI 2.1
  12. RS232
  13. USB-C (5V/2A)
  14. USB 2.0 (5V/1.5A)
  15. IR Receiver
  16. Menu Control: Brightness Level
  17. Menu Control: Volume
  18. Menu Control: Input Source
  19. Power Button
  20. Indicator Light
Visit Us
  • www.viewsonic.com
  • SPECIFICATION
    Screen Size: 216''
    Display Area (mm): 4800 (H) x 2700(V)
    Native Resolution: 1920x1080
    Panel Technology: Direct view LED
    LED Package Type: SMD 3 in 1
    Bonding Wire: Gold
    Pixel Pitch (mm): 2.50
    Refresh Rate: 4440Hz
    Brightness (max.): 600 nits (8 levels adjustable)
    Contrast Ratio (typ.): 6000:1
    Orientation: Landscape / Portrait
    Viewing Angles (typ.): H = 160, V = 160
    LED Lifetime (typ.): 100,000 Hours
    Local Storage: Total 64GB
    (56GB available storage)
    Embedded OS: Android 9.0
    Resolution Support: VGA(640 x 480) to
    1080p(1920 x 1080)
    HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160P/60Hz
    Horizontal Frequency: 23-120 kHz
    Vertical Scan Rate: 15-135 Hz
  • INPUT
    HDMI: x5
    (HDMI 2.1 x 1, HDMI 2.0 x 2, HDMI 1.4 x 2)
    USB Type A: x3
    (USB2.0 x3)
    RJ45 Input (Internet): x1
    IR in: x1
    Wi-Fi Input: 2.4G/5G Hz
    USB Type C: x1
    (Video input、 Power output (5V/2A))
    HDBaseT: x1
    (1080P@100m、4K30Hz@70m)
  • OUTPUT
    HDMI out: x2
    (HDMI 2.0 external x1,internal x1)
    Speaker: 20W x2 (harman kardon)
    Audio out (3.5mm): x1
    USB Type A (Power): Shared with USB input
    (5V/1.5A x3)
  • CONTROL
    RJ45 (LAN control): x1
    USB Type A (Services): x1(shared with USB A input)
    RS232 (DB 9-pin female): x1
    IR Receiver: x1
  • OTHERS
    Power Supply Voltage: 100-120V/30A~ 50/60Hz or 220-240V/15A~ 50Hz
    (vary by country)
    Power Consumption: 2500W (typ), 4000W (max)
    <0.5W (Sleep),<0W (Off)
    Operating Temperature: 0~40℃
    LED Module Quantity: 128
    Ingress Protection Rating: IP30(Front)
    Net Weight: 661 lbs
    (300 kg)
    Gross Weight: 1129 lbs
    (512 kg)
    Screen Dimensions (WxHxD): 189.4x111x1 inches
    (4810 x 2820 x 25 mm)
    Screen Dimensions (WxHxD) with wall mount: 189.4x111x2.2 inches
    (4810 x 2820 x 57 mm)
    Packing Dimensions (WxHxD): 109.4x27.9x37 inches
    (2780x710x940 mm)
  • STANDARD ACCESSORIES
    Power Cord: x2
    HDMI Cable: x1(5m)
    LAN Cable (Cat 5A): x1(5m)
    IR Extender Cable: x1(3m)
    Remote Control: x1
    QSG: x1
    Wall Mount: x1
    Spare Parts: LED PCB Unit x7
    Maintenance Tool: LD-MK-001 x1
  • OPTIONAL ACCESSORIES
    Maintenance Tool: LD-MK-001
    ViewBoard Cast Button(USB-C): VB-WPS-001
    ViewBoard Cast Button(USB-A+HDMI): VB-WPS-003
