- Abmessungen
Physisch mit Fuß: 472 x 408 x 225
Physisch ohne Fuß: 472 x 327 x 65
Verpackung (B x H x T): 526 x 448 x 127
- Zertifikate
TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R, Hygienic (20 copies), UL, cUL, FCC-B (ICES), ICES-003B, NOM, SASO, ENERGY, ENERGY STAR, C-Tick, KTL/MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark CCC, VCCI, WEEE, RoHS
- Lieferumfang
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- AUDIO
Lautsprecher: 2x2.5-watts
- Anschlüsse
Analog: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable) (HDCP enabled)
Stromversorgung: 3-pin AC plug (CEE22)
- Stromversorgung
Spannung: AC 100–240V, 50/60Hz (auto switch), internal power supply
Verbrauch: 38 watt (typ.), <1 watt in power save mode
- Bedienungselemente
Grundausstattung: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall
- Betriebsbedingungen
Temperatur: 0°C–40°C
Feuchtigkeit: 20%–90% (non-condensation)
- Gewicht
Netto mit Fuß: 4.9kg
Brutto: 6.4kg
- Videoeingang
Frequenz: Fh: 24–82kHz, Fv: 50–75 Hz
Synchronisierung: H/V separate (TTL), composite, sync on green
Analog: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Digital: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
- Energieverwaltung
TCO’03 and ENERGY STAR standards
- Sicherheit
Kensington security port
- Wandhalterung
VESA FDMI 100mm x 100mm
- Ergonomie
Neigung: -5°/+20°
