The Definitive Standard of Quality
The VP2365wb is one of ViewSonic’s new LCD VP series monitors that utilize the power of IPS panel technology. With true 8-bit colour palette, high contrast ratio and wide viewing angles coupled with 1920x1080 Full HD resolution, VP2365wb is the perfect solution for designers, manufacturers, medical applications and movie production. An integrated 4-port USB hub enables cluster free connectivity, ergonomic functions with pivot, height adjust, tilt, swivel and slim bezel make the VP2365wb an amazing monitor. ECO Mode offering up to 40% saving on power consumption and , ViewSonic's strongest pixel performance guarantee, gives you confidence in your investment. The VP2365wb will also contribute to a greener world with its compliant power management features and environment-friendly materials.
REVIEWS
SPECIFICATIONS
- COLORSBlack
- LCDType: 58cm / 23" Colour a-Si TFT Active Matrix LCD
Contrast Ratio: 1000:1 (typ.)
Viewing Angles: 178° (H), 178° (V) (CR≧10)
Display Area: 509.18 mm (H) * 286.42 mm (V)
Optimum Resolution: 1920 x 1080
Response Time: 14ms (on/off) / 5ms (G to G)
Light Source: 50,000hrs (typ.)
Panel Surface: Anti-Glare type, Hardness (3H)
Pixel Pitch: 0.265 mm(H) x 0.265 mm(V)
Colour Gamut: 82% NTSC (CIE1976)
Brightness: 250 cd/m² (typ.)
Dynamic Contrast Ratio: 20,000:1 - COMPATIBILITYPC: VGA up to 1920 x 1080 Non-Interlaced
Mac®: Power Mac (up to 1920 x 1080 )
- DIMENSIONSPhysical (WxHxD): 548 mm x 433 mm x 250 mm
- REGULATIONSUL, CUL, FCC-B (ICES), CB, CE, TCO'03, ICES-003B, ISO13406-2, TUV/GS,
TUV ERGO(covers ISO13406-2 & MPRII), TUV-S, NOM, GOST-R, HYGIENIC
(20 copies), CCC, BSMI, PSB,
C-TICK, KTL/MIC, SASO, WEEE, RoHS, EPEAT Silver - CONNECTORAnalogue: 15 pin mini D-sub x 1
Digital: DVI-D x1
USB: USB 2.0 up-stream x 1 , down-sream x 4
Power: 3-pin plug (CEE22) x 1 - POWERVoltage: AC 100-240V AC ; 50/60 Hz (Switch)
Consumption: 130 W (max.) / 110 W (typ.) - CONTROLSBasic: [1], [2], AC power switch, Up[▲], Down[▼]
Main Menu: Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB, DVI),
Colour Adjust, (sRGB, 9300K, 7500K, 6500K, 5000K, User Colour [R, G, B]),
Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine
Tune, Sharpness, Dynamic Contrast, Aspect ratio [1:1, Fill Aspect Ratio,
Full Screen], Display Mode [PC Mode, HD Mode]), Setup Menu (Language,
Resolution Notice, OSD Position, OSD Timeout, OSD Background, OSD
Pivot), Memory Recall - OPERATING CONDITIONSTemperature: 0°C - 40°C (32°F - 104°F)
Humidity: 10% - 90% (no condensation) - WEIGHTNet: 6.8 Kg (15 lbs)
- VIDEO INPUTSync: Separate Sync / Composite Sync / SOG
Analogue: RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital: DVI (TMDS, 100 ohms)
Frequency: Fh: 22 – 82 kHz , Fv : 50 – 75 Hz - VESA MOUNT COMPLIANTMeet VESA (100mm x 100mm) Standards
- ERGONOMICSTilt: 20~-5 degrees
Swivel: 360 degrees
Height Adjustment: 0~135 mm
Rotation: 0~90 degrees (Clockwise)
