- DIMENSIONS
Physical With Stand: 460 x 416 x 206 (with stand)
Physical Without Stand: 460 x 352 x 62 (without stand)
W x H x D mm: 534 x 509 x 150 (packaging)
- REGULATIONS
TCO’03, TÜV/GS, TÜV/Ergo, ISO13406-2 (pixel failure class II), CE, CB,
GOST-R, PSB, Energy Star ,YCO03, UL/cUL, FCC-B, ICES 003, NOM,
Argentina-TÜV/S, SASO, BSMI, C-Tick, MIC, CCC, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, D-sub video cable, audio cable, Quick Start Guide,
ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Audio: 3.5mm stereo audio line-in
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 35 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select [2], mute
OSD: Auto image adjust, contrast, brightness, audio (volume, mute), ViewMatch®
colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution,
H/V frequency, pixel clock, model number, serial number), manual image
adjust (H/V position, H size, fine tune, sharpness), setup menu (language,
resolution notice, OSD position, OSD timeout, OSD background), OSD/power
lock, memory recall
- OPERATING CONDITIONS
Temperature: 5°C–35°C
Humidity: 20%–80% (non-condensation)
- WEIGHT
Net: 5.0kg (with stand)
Gross: 6.5kg
- VIDEO INPUT
Frequency: Fh: 30–82kHz, Fv: 56–75Hz
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Sync: H/V separate (TTL)
- POWER MANAGEMENT
Meets TCO’03 and Energy Star® standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FDMI 75mm x 75mm
- ERGONOMICS
Tilt: Down 5°, Up 20°
- AUDIO
Speakers: 2 x 1.5 watt integrated stereo speakers
