- REGULATIONS
TCO´03, TÜV/GS, ISO 13406-2 (pixel fault class 2) TÜV-S, TÜV/Ergo, UL,
CUL, FCC-B, CB REPORT, CE, EPA, NOM, NEMKO, SEMKO, DEMKO,
FIMKO, GOST-R, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, ENERGY
- AUDIO
Speaker: 2 x 3 watt
Amplifier: 3 watt @ 1kHz
- INPUT SIGNAL
Frequency: Fh: 30~82kHz, Fv: 50~85Hz
Analogue: RGB Analogue (75 ohms, 0.7 Vp-p)
Digital: DVI-D (TMDS, 100 ohms)
Sync: H/V separated (TTL)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Audio: 3.5mm stereo audio line in
Power: 3-pin AC plug
- POWER
Voltage: AC 100–240V (universal), 50–60Hz (auto switch), internal power supply
Consumption: <50 watt (typ.), ≤ 1 watt in suspend mode
- CONTROLS
OSD: Auto image adjust, brightness, contrast, input select (analogue, digital),
colour adjust (sRGB, 9300K, 6500K, 5400K, 5000K, user RGB), information
(mode, model number, serial number), audio (volume, balance,
bass, treble, mute), manual image adjust (H./V. position, H. size, fine
tune, sharpness), setup menu (language, resolution notice, OSD position,
OSD timeout, OSD background), memory recall
Physical: Power on/off, menu, up, down, select, mute, volume up/down
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 10-65% (non-condensing)
- WEIGHT
Net: 6.8kg
- POWER MANAGEMENT
Meets TCO’03, ENERGY and Energy Star standards
- ERGONOMICS
Down 5°, Up 20°
