- DIMENSIONS
Physical With Stand: 570mm x 463mm x 260mm (22.4" x 18.2" x 10.2")
Physical Without Stand: 570mm x 400mm x 103mm (22.4" x 15.8" x 4.0")
- REGULATIONS
UL, cUL, FCC-B, NOM, ENERGY STAR , TUV-S CE, ISO13406-2 Class II, WEEE, RoHS, GOST-R / Hygenic
- PACKAGE CONTENTS
LCD display, power cable, video cable, audio cable, User Guide
- WARRANTY
One-year limited warranty on parts, labor and backlight.
- AUDIO
Speaker: 2x2 watt
- RECYCLE/DISPOSAL
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
- CONNECTOR
Analogue: 15-pin mini D-sub
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100–240V (universal), 50–60Hz (auto switch)
Consumption: 85W (typ)
- CONTROLS
Basic: Power, 2, up, down, 1
OnView®: Auto image adjust, brightness, contrast, color adjust (sRGB, 9300K, 6500K, 5400K, user color), H. position, V. position, H. size, OSD position, OSD timeout, OSD background, fine tune, sharpness, language, input select, recall
- OPERATING CONDITIONS
Temperature: 32-104ºF (0-40ºC)
Humidity: 20–80% (non-condensing)
- WEIGHT
Net With Stand: 5.8 kg (12.7 lb).
Net Without Stand: 5.3kg (11.7 lb).
Gross With Stand: 7.3kg (16.1 lb).
- VIDEO INPUT
Frequency: Fh : 30-80kHz , Fv : 56-60Hz
Sync: H/V separated (TTL)
Analogue: RGB analog (75 ohms, 0.7 Vp-p)
- POWER MANAGEMENT
ENERGY STAR standards
- ERGONOMICS
Tilt -5 /+15
- VESA MOUNT COMPLIANT
Meet VESA ( 75mm X 75mm ) Standards
