ND4210w
107cm / 42" HD LCD Network Display with intergrated internet protocol (IP) networking
Dynamic digital signage
ViewSonic's ND4210w 107cm / 42" HD network display is one of the latest generation LCD displays with integrated industry standard Internet Protocol (IP) networking – another time ViewSonic sets new standards to access digital content. The ND4210w directly decodes video over IP and can be REMOTELY MANAGED FROM VIRTUALLY ANYWHERE IN THE WORLD via the Internet. ViewSonic brings its heritage of award- winning display and media networking technologies to the world of commercial digital signage. Especially designed for business installations, ND4210w CUSTOMISABLE DISPLAYS CAN PLAY UNIQUE OR IDENTICAL CONTENT in multiple locations within a building, across a large business campus or even in diverse locations across the country. Brilliantly display call centre information boards, window advertisements, transportation depot information, restaurant menus, and in-store merchandising.
SPECIFICATIONS
- LCDType: 107 cm / 42" IPS colour TFT active matrix, wide 1366 x 768
Contrast Ratio: 1600:1 (typ.)
Viewing Angles: 178° horizontal, 178° vertical (at 10:1)
Brightness: 500cd/m²
Display Area: 93.0cm (horizontal) x 52.3cm (vertical), 107cm diagonal
Optimum Resolution: 1366 x 768@60Hz
Response Time: 8ms (off-on-off) (typ.)
Aspect Ratio: 16:9
Panel Surface: Anti-glare (3H)
Colour Support: 16.7M colours (8-bit) - DIMENSIONSPhysical (WxHxD): 1243 x 739 x 304 (with stand)
- REGULATIONSCB, UL/cUL, FCC - 15B/IC - ES003B, CE (EN55022/55024/LVD), C-Tick, NOM-019, TÜV-S Mark, CB, SASO, SABS, CCC, BSMI, PSB, GOST-R
- PACKAGE CONTENTSLCD Monitor, power cable, Ethernet cable, remote control, batteries, Quick Start Guide, ViewSonic Wizard CD-ROM
- CONNECTORPower: 3-pin AC plug (CEE22)
USB: 2 x USB (4-pin Typ A) (support for HIB and WLAN connection)
Audio: 1 x RCA set R/L
1 x external speakers R/L (8 ohms)
Network/Daisy Chain: 2 x RJ-45 - POWERVoltage: AC 100– 240V, 50/60Hz (auto switch), internal power supply
Consumption: 390 watt (typ.), +/- 10% watts - OPERATING CONDITIONSTemperature: 5°C – 40°C
Humidity: 20% – 85% (non-condensation) - WEIGHTNet: 33kg
Gross: 41kg - DECODINGVideo: MPEG-1,2,4, Macromedia® Flash™
Audio: MPEG-1 (layers 1, 2, 3), MP3, WMA, AAC, Dolby® AC-3 (pass through) - STREAMING PROTOCOLTypes: HTTP, UDP, RTP, IP/TV (separate A/V), ISMA, local file playback
- IMAGE FILEFormats: JPEG, BMP
- VESA MOUNT COMPLIANTVESA FDMI 200mm x 200mm
- VIDEO CHIPSETSigma EM8621L
Freescale MPC8247 - VIDEO SCANNING FORMATSDTV/EDTV (480i/p, 576i/p), HDTV (720p, 1080i)
- STORAGE/MEMORYHDD: 40GB
RAM: 128MB
Flash: 64MB
RAM Sigma: 64MB
CompactFlash: up to 1GB
